| SWIVEL | RIGID | SIDE BRAKE | TOTAL BRAKE | Dia x Width (mm) | Total Height (mm) | Plate Size (mm) | Hole to Hole (mm) | Hole Dia (mm) | Load (kg) |
|---|---|---|---|---|---|---|---|---|---|
| J38 NZB050 S | J38 NZB050 R | – | J38 NZB050 SB2 | 50 X 38 | 79 | 84 X 84 | 64 X 64 | 8.5 | 300 |
| J38 NZB065 S | J38 NZB065 R | – | J38 NZB065 SB2 | 65 X 50 | 95 | 100 X 100 | 80 X 80 | 9 | 500 |
| J38 NZB075 S | J38 NZB075 R | – | J38 NZB075 SB2 | 75 X 50 | 105 | 100 X 100 | 80 X 80 | 9 | 600 |
NZB Series
AMC J38 Series Heavy Duty Casters
Load Range: 300-600kg/pc
| Wheel | NZB Series |
| Tread | Nylon (Black) |
| Centre | Nylon |
| Bearing | Double Ball |
